VIER Size 3 Fixed Power Door Closer with Arm and body (P.A Bracket Inc)

Stock Code: VDC003S
1-2 day lead time
£15.00 (exc VAT) per 1
Quantity: - +

Catagory Topper

PRODUCT SPECIFICATION

  • Closing force EN Size 3
  • Door size (max) Width (mm) 950
  • Weight (kg) 60
  • Mechanism: Rack & Pinion
  • Parallel arm bracket: Yes
  • Angle of opening 180°
  • Non handed: Yes
  • Power adjustment by spring: No
  • Power adjustment by position: No
  • Adjustable closing speed: Yes
  • Adjustable latch speed: Yes
  • Adjustable backcheck: No
  • Adjustable delayed action: No
  • Corrosion Grade 3 - Hours 96
  • Guarantee Years 10



BODY DIMENSIONS

  • Length (mm) 180
  • Width (mm) 42
  • Depth (mm) 65

 Technical Data

FIRE TESTING

  • Successfully fire tested in accordance with the requirements of BS EN1154-1996,BS EN1634 suitable for use on 30/60-minute timber fire doors

CERTIFICATION

  • CE marked (Certificate BS EN 1634 1996)
  • CERTIFIRE approved (Certificate CF5549)

BS1634BS1996Timber 30/60Certfire CF5549


Technical Information
Zoo Hardware

FinishSilver
Max Door Weight60kg
Max Door Width950mm
BackcheckNo
Delayed ActionNo
ManufacturerZoo
