DeWALT DCD796N 18V XR Brushless Compact Combi Drill (Body Only)

Stock Code: DCD796N

In Stock

Descriptions

DeWALT Power Tools

18V COMBINATION DRILL

The new DeWalt DCD796 compact combi hammer drill featuring brushless technology is up to 30% more powerful than the DCD795 with 460 Units Watts Out (UWO).

Supplied body only. Batteries & chargers are sold separately.

Features

Brushless Motor Technology for excellent efficiency
Ultra compact, lightweight design allows use in confined spaces
Two speed all metal transmission for increased runtime and longer tool life
Drill Driver and Hammer feature for multiple applications
15 position adjustable torque control for consistent screw driving into a variety of materials
Intelligent trigger design allows for total control of application
Improved ergonomic design with rubber grip over mould improving users comfort
Improved air flow to the motor for cooler electronics and incrreased power
3 position super bright LED light
Li-Ion battery packs allows for superior insertion and removal with state of charge indicator

Technical specifications

Nominal Battery Voltage: 18 V

No load speed: 0 - 550 / 2000 min?¹

Impacts per Minute (IPM): 0 - 9350 / 34000 min?¹

Max. Drilling Diameter in Wood: 40 mm

Driving Shank: 1/2"-20UNF "

Drill Chuck Capacity: 1,5 - 13 mm

Tool weight without battery: 1,3 kg

Product Dimensions (L): 173 mm

Battery Chemistry (Ni-Cd / Ni-MH / Li-ion): Li-ion

Drilling Capacity Wood : 40 mm

Specifications

Product Type	Combi Drill
Manufacturer	DeWalt
